| Pixel Configuration |
SMD2020 |
| Pixel Pitch (mm) |
4 |
| Pixel matrix per panel |
72x30 |
| Pixel density (pixels/sq.m.) |
62500 |
| Cabinet Dimensions (W×H×D) / (mm) |
ー |
| Module Dimensions (W×H×D) / (mm) |
288 × 120 × 15.4 |
| Panel material |
ー |
| Cabinet weight (kg/panel) |
ー |
| Module weight (kg/panel) |
0.27 |
| Color Grayscale (Bit) |
14 |
| Gray Scale per Color (level) |
16384 |
| Refresh Rate (Hz) |
720 |
| Driving Type |
1/15 |
| Brightness (nit) |
≧1000 |
| Optimal Horizontal Viewing Angle (°) |
≧140 |
| Optimal Vertical Viewing Angle (°) |
≧140 |
| AC Input Voltage (V) |
AC220-240 |
| AC Input Frequency (Hz) |
60 |
| AC Input Power Maximum Value (W/㎡） |
≧660 |
| Storage Temperature (℃) |
-30～60 |
| Operating Temperature (℃) |
-20～50 |
| Storage Humidity (RH) |
10％～90％ |
| IP rating (Front / Rear) |
IP40 |
| Operating Humidity (RH) |
10％～90％ |
| Lifetime Typical Value (hrs) |
100000 |
| Cabinet insttallation type |
ー |
