| Physical Pitch |
6.9 mm |
| Pixel Configuration |
SMD |
| Pixel Density |
20,736 pixels/m² |
| 10,368 pixels/panel |
| Module Dimensions (mm) |
500 × 125 |
| Panel Dimensions (W × H × D) (mm) |
500 × 1,000 × 69 |
| No. of Modules Per Panel (W × H) |
1 × 8 |
| Physical Resolution of Module (W × H) |
72 × 18 |
| Physical Resolution of Panel (W × H) |
72 × 144 |
| Weight Per Panel |
9.3 kg/panel |
| Weight Per m² |
18.6 kg/m² |
| Processing |
16 bit |
| Colours |
281 trillion |
| Contrast Ratio |
3,000：1 |
| Average Power Consumption |
100 - 168 w/panel |
| Power Consumption (Max) |
336 w/panel |
| Operating Temp/Humidity |
-20 - 50℃/ 10% - 90% |
| Storage Temp/Humidity |
-30 - 60℃/ 10% - 90% |
| Brightness |
5,000 nits |
| Refresh Rate |
1,920 - 3,840 Hz |
| Horizontal Viewing Angle |
140° |
| Vertical Viewing Angle |
120° |
| Expected LED Lifetime (Max) |
100,000 Hrs |
| Max Stacking |
12 panels |
| Max Hanging |
12 panels |
| Servicing |
Front and Back |
| IP Rating |
IP 65 |
| Certification |
CE, EMC ClassA, RoHS |
